2027 KTM 85 SX 19/16
The last step awaits. The KTM 85 SX 19/16 is ready to raise the speed for you. Developed on track and at an international level, the KTM 85 SX 19/16 boasts significantly enhanced handling, searing power delivery and proven READY TO RACE DNA through its components and pedigree. You spoke, we listened. We developed. Now continue the journey. Fast.
Key Specifications
- Engine: 1-cylinder, 2-stroke engine
- Displacement: 84.9 cm³
- Transmission: 6-speed
- Front suspension: XACT 43 WP Upside-Down fork, Ø 43 mm
- Rear suspension: XACT WP PDS mono shock
- Seat height: 871 mm
- Ground clearance: 333 mm
- Tank capacity: 5.4 l
- Weight without fuel: 69 kg
| Brand | KTM |
|---|---|
| Year | |
| KTM Category | Motocross |
| Engine - Design | 1-cylinder, 2-stroke engine |
| Engine - Displacement | 84.9 cm³ |
| Engine - Transmission | 6-speed |
| Engine - EMS | Keihin PWK 28 |
| Engine - Engine oil | Motorex Formula 4T 15W/50 |
| Engine - Clutch drive teeth | 64 |
| Engine - Primary drive | 20:64 |
| Engine - Clutch | Formula hydraulics, multi-disc clutch, Wet |
| Engine - Engine cylinder | Single cylinder |
| Engine - Engine stroke | 2-Stroke |
| Chassis - Frame design | Central-tube frame with double-cradle |
| Chassis - Front brake | Disc brake |
| Chassis - Rear brake | Disc brake |
| Chassis - Rear subframe | Aluminium / Polyamide Glass Fiber |
| Chassis - Chain | 428, Non-sealed |
| Suspension Front | |
| Suspension - Rear suspension | XACT WP PDS mono shock |
| SUSPENSION TRAVEL (FRONT) | 278 mm |
| SUSPENSION TRAVEL (REAR) | 289 mm |
| Suspension - Front type | WP XACT |
| Suspension - Front adjust | Compression and rebound adjustable |
| Suspension - Rear adjust | Preload adjuster |
| Dimensions - Seat height | 871 mm |
| Dimensions - Ground clear | 333 mm |
| Dimensions - Tank capacity | 5.4 l |
| Dimensions - Weight no fuel | 69 kg |
