2027 Husqvarna TC 85 17/14
Continuing to utilise the latest 2-stroke technology, the engine remains well ahead of its 85 cc competition. Overall performance can be customised depending on rider preference or track conditions too, as the TC 85 benefits from two engine maps. A close ratio six-speed gearbox and hydraulic clutch completing the build of this highly competitive machine.
Note: Model-specific use, homologation and road-legal status should be confirmed before publishing.
Key Specifications
- Engine: 1-cylinder, 2-stroke engine
- Displacement: 84.9 cm³
- Transmission: 6-speed
- Front suspension: XACT 43 WP Upside-Down fork, Ø 43 mm
- Rear suspension: XACT WP PDS mono shock
- Seat height: 845 mm
- Ground clearance: 308 mm
- Tank capacity: 5.4 l
- Weight without fuel: 68 kg
| Brand | Husqvarna |
|---|---|
| Year | |
| Husqvarna Category | Motocross |
| Engine - Primary drive | 20:64 |
| Engine - Transmission | 6-speed |
| Engine - Cooling | Liquid cooled |
| Engine - Secondary gear ratio | 13:46 |
| Engine - Starter | Kickstarter |
| Engine - Stroke | 48.95 mm |
| Engine - Bore | 47 mm |
| Engine - Clutch | Formula hydraulics, multi-disc clutch, Wet |
| Engine - Displacement | 84.9 cm³ |
| Engine - EMS | Keihin PWK 28 |
| Engine - Design | 1-cylinder, 2-stroke engine |
| Chassis - Weight no fuel | 68 kg |
| Chassis - Tank capacity | 5.4 l |
| Chassis - Wheelbase | 1282 mm |
| Chassis - Front brake diameter | 240 mm |
| Chassis - Rear brake diameter | 220 mm |
| Chassis - Front brake | Disc brake |
| Chassis - Rear brake | Disc brake |
| Chassis - Chain | 428, Non-sealed |
| Chassis - Frame design | Central-tube frame with double-cradle |
| Chassis - Front suspension | Ø 43 mm, XACT 43 WP Upside-Down fork |
| Chassis - Ground clearance | 308 mm |
| Chassis - Handlebar | Aluminium, tapered Ø 28/22 mm |
| Chassis - Rear suspension | XACT WP PDS mono shock |
| Chassis - Seat height | 845 mm |
| Chassis - Silencer | Aluminium |
| Chassis - Steering head angle | 63.5 ° |
| Chassis - Rear subframe | Aluminium / Polyamide Glass Fiber |
| Chassis - Travel front | 278 mm |
| Chassis - Travel rear | 289 mm |
| Chassis - Tyre dimensions | 70/100; 90/100 |
| Chassis - Wheels | 1.4 x 17"; 1.6 x 14" |
